Metal Push Button Waterproof type Screw Type or Pin Type
Overview
Quick Details
- Certification: CE
- Place of Origin: Zhejiang, China
- Brand Name: CNLD
- Model Number: According Selection manual
- Protection Level: IP65
- Max. Current: 3A
- Max. Voltage: 250V
- LED: No
- Product Name: Metal push button switch
- Mounting Hole Size: 12,16,19,22,25 mm & customization
- Operation Type: Momentary / Reset
- Switch Combination: 1NO normally open , 1NO 1NC ,2NO 2NC & Customization
- Switch rating: 3A 250VAC
- Head Type: High head , Flat head, Ball head
- Terminal type: 2 screw terminals or pin type
- Enclosure Material: Brass nickelage & SS
- Application: Industrial Control
- Product type: Momentary push button switch
Packaging & Delivery
- Selling Units: Single item
- Single package size: 5X5X5 cm
- Package Type: 1NO 3A/36VDC High Round Cap Flush Screw Terminals 16mm 5/8" Metal Momentary Push Button Switch
-
1: Neutral packing : plastic bag for goods+ inner box bubble+ inner box +carton
2: Upon customers' request, but the price is different with neutral packing
- Lead Time:
-
| Quantity(Pieces) |
1 - 1000 |
>1000 |
| Est. Time(days) |
3-10 |
To be negotiated |
Parameter
|
Metal Push Button Switch |
|
Mounting hole size : |
12,16,19,22 etc |
|
Switch value: |
2A/36V DC |
|
Operation type: |
Momentary |
|
Contact configuration: |
1NO,1NC / 2NO,2NC |
|
Head shape： |
Flat,high head ,ball head |
|
Crust material: |
Nickel-plated brass |
|
Terminal type: |
Pin terminal |
|
Electrical life : |
≥50,000 times |
|
Mechanical life: |
≥1，000,000 times |
|
Operation temperature: |
-40℃~+80℃ |
|
Contact Resistance: |
≤50mΩ |
|
Insulation Resistance: |
≥1000mΩ |
|
Operation stroke: |
0.5mm, 3mm |
|
Protection grade : |
IP65 |
|
Contact material: |
Silver alloy |
Application: Outdoor controls, Industrial machinery, Medical equipment, Security equipment, Mass-transit, lift trucks, Elevators, Food processing equipment, Fishing vessels, Military equipment, Crane gantry equipment, etc.
Service
1. OEM Manufacturing welcome: Product, Package, Color. , Laser symbol, Illuminated symbol for big order. We have a 5 years experience professional work team can satisfy special design, modification and requirement.
2. Any inquiries will be replied with in 24 hours.
3. Report of production situation before delivery.
4. Keep recommending new items for customers.
