Outdoor or Indoor Charging Distribution Cabinet
Product Description
Material
Body : 1.2mm sheet steel till size XJBS-A 8060/20 then 1.5mm
Mounting plate : 1.5mm sheet steel till size XJBS-A 8060/20 then 2.0mm
Door :1.2mm sheet steel till size XJBS-A 8060/20 then 1.5mm
Surface finish
Body and door :Epoxy polyester powder coating textured finish
Mounting plate: Epoxy polyester powder coating flat finish
Color
Body and door :RAL7032/RAL7035
Mounting plate: RAL 2000 OR galvanized steel
Protection degree:IP 65
Against mechanical impacts: IK10
General of Distribution Box:
| 1.Seal Strip forming by Full-automatic Pouring Machine One-time, Self-skinning.Waterproof, Fireproof, High Temperature Resistance, High Intensity, Nice Outlook,etc. |
| 2.The Hinge Connected by Flange Screw, so that the Door can be Exchanged between Right and Left.No Self Off and No Crack. |
| 3.Brand New Structure for Screw Mounted, and Sealing Ring add to Connection of Bolts and Screws.Waterproof and Dustproof. |
| 4.Piercing Installation for Bottom Board,and Flange Screw for Connecting, Thus Easy to Assemble and Disassemble, and Much Stronger and Durable. |
| 5.New Design of Bottom Board Structure, can Acheive Greater Load-bearing, and can Meet Electrical Installation Requirements Better. |
Supply:Enclosure, door ,Galvanized or orange painted mounting plate, locking system, gland plate, sealing gasket and fixing accessories.
Customized size, thickness, process requirements is accepted.
waterproof outdoor electrical power wall mount metal enclosures
| Item No. |
Width(mm) |
Height(mm) |
Depth(mm) |
Width for Installation(mm) |
Height for Installation(mm) |
| JXF1-3025/14 |
250 |
300 |
150 |
190 |
325 |
| JXF1-3025/18 |
250 |
300 |
180 |
190 |
325 |
| JXF1-3030/14 |
300 |
300 |
150 |
240 |
325 |
| JXF1-3030/20 |
300 |
300 |
200 |
240 |
325 |
| JXF1-4030/14 |
300 |
400 |
140 |
240 |
425 |
| JXF1-4030/20 |
300 |
400 |
200 |
240 |
425 |
| JXF1-5040/14 |
400 |
500 |
140 |
340 |
525 |
| JXF1-5040/20 |
400 |
500 |
200 |
340 |
525 |
| JXF1-5040/23 |
400 |
500 |
230 |
340 |
525 |
| JXF1-6040/14 |
400 |
600 |
140 |
340 |
625 |
| JXF1-6040/20 |
400 |
600 |
200 |
340 |
625 |
| JXF1-6040/23 |
400 |
600 |
230 |
340 |
625 |
| JXF1-6050/14 |
500 |
600 |
140 |
440 |
625 |
| JXF1-6050/20 |
500 |
600 |
200 |
440 |
625 |
| JXF1-7050/20 |
500 |
700 |
200 |
440 |
725 |
| JXF1-7050/25 |
500 |
700 |
250 |
440 |
725 |
| JXF1-8060/20 |
600 |
800 |
200 |
540 |
825 |
| JXF1-8060/25 |
600 |
800 |
250 |
540 |
825 |
| JXF1-10080/20 |
800 |
1000 |
200 |
740 |
1025 |
| JXF1-10080/25 |
800 |
1000 |
250 |
740 |
1025 |
Our Services
Warranty Service:
We 100% Gurantee your Satisfaction
1 Pls report us if there are any problem, we will solve it ASAP.
2 This items comes with 1 YEAR warranty.
Equivalent replacements can be provided with shipment of your next order if the products are broken for unartificial factors within 1 YEAR; however photos are needed for us to find the factors of damaging them.
3 Shipping and handling fees are not refundable for return or exchange items.
Philosophy of the Company:
Excellent design,Excellent make.Excellent service.
We have more electrical equipment to provide for your reference. At the same time, if you have any idea, you can Send Inquiry directly.
